About Rampart FR
Premium Multi-Hazard Outerwear Protection: Electric Arc, Flash Fire, Static Electricity, High Visibility, Waterproof, Windproof, Breathable
NASCO ARCWEAR™ RAMPART FR™
Designed for long-duration rain events but perfect for every inclement weather condition, the Rampart FR™ system is outstanding protective outerwear. The Rampart FR™ system combines a breathable moisture management barrier with a moisture management system to engineer comfort from inside out.
Rampart FR™ provides the wearer with protection from the outside in with an electrostatic dissipative shell in combination with a Polartec® Power Dry® moisture management layer. This combination of layers includes superior electric arc ratings and flash fire results using Rampart FR™ zonal protection design.
NASCO ARCWEAR™ RAMPART FR™ SERIES
The table below summarises Rampart FR's ATPV, NFPA 70E PPE Category (HRC), Flash Fire Total Body Burn Percentage and ANSI 107 High Visibility Class/Type.
SERIES | BRAND | COLOUR | ATPV CAL/CM2 | NFPA 70E CAT | TOTAL BODY BURN % | ANSI 107 CLASS/TYPE |
|---|---|---|---|---|---|---|
8000 | Rampart FR™ | Fluorescent Lime Yellow | 13 | 2 | 11.7 | 3/R |
8000 | Rampart FR™ | FLY with Liner | 22 | 2 |
| 3/R |
4.9 (2nd Degree) | ||||||
6.8 (3rd Degree) |
FABRIC SPECIFICATIONS
- Fabric - ExoGuard 297gsm/8.75oz.
- Moisture Barrier - Urethane Composite - Breathable.
- Inner Layer - Polartec® Power Dry® - 177gsm/5.2oz.
- Finished Weight - 473gsm/13.95oz (Rampart FR™ Jacket with Polartec® Power Dry Liner).
HOW RAMPART FR™ PROTECTS
- Electric Arc
- Flash Fire
- Static Electricity
- High Visibility
- Waterproof
- Windproof
- Breathable
POLARTEC® POWER DRY® FR TECHNOLOGY
Polartec® Power Dry® FR is engineered to deliver superior mechanical wicking.
This bi-component fabric technology is constructed with a hydrophilic interior to pull moisture away from the skin and transfer it to the outer layer. Power Dry® FR's exterior surface area disperses and releases this moisture for more efficient dry times. Continuous evaporation prevents saturation and regulates temperature in both hot and cold conditions.
TESTING STANDARDS
- NFPA 2112 Flash Fire
- NFPA 70E Electric Arc
- ISO 11612 Heat and Flame
- EN 61482-12 Electric Arc
- ANSI 107 High Visibility
- ISO 20471 High Visibility
RAMPART FR™ REVOLUTIONARY OUTERWEAR PROTECTION
POLARTEC® FR TECHNOLOGIES
